MULTI DOOR INTERFACE
This interface manages multiple interface Card Readers for global multi door access controller system anti-pass back. Interface support advance building automation function – Eg: Can turn on light according to pre-set schedule or pin code. It also upgrade the security level to avoid intruder gaining access by damaging the reader.
MAC302M – Dual Reader Interface
-2 Weigand readers
-Maximum users : 3000
-Expiry date setting : N/A
-Memory transaction : 1456
MAC316M – 14+2 Multi-Reader Interface
-Maximum readers : 14 + 2
-Maximum users : 16000
-Expiry date setting : Yes
-Memory transaction : 32000
MAC318M – 16+2 Multi-Reader Interface
-16 RS485 + 2 Weigand readers
-Maximum users : 15000
-Expiry date setting : Yes
-Memory transaction : 11000
MAC416M – 16 Relay Output Interface
16 relay interface for lift access system. Each interface can be looped to support multiple of 16 floors.
MAC432M – 32 Relay Output Interface
32 relay interface for lift access system. Each interface can be looped to support multiple of 32 floors.
AR716-E02 – Soyal 2 Reader Interface
-2 Weigand readers
-Maximum users : 3000
-Expiry date setting : N/A
-Memory transaction : 1456
AR716-E16 – Soyal 14 + 2 Reader Interface
-Maximum readers : 14 + 2
-Maximum users : 16000
-Expiry date setting : Yes
-Memory transaction : 32000
AR716-E18 – Soyal 16 Reader Interface
-16 RS485 + 2 Weigand readers
-Maximum users : 15000
-Expiry date setting : Yes
-Memory transaction : 11000
AR401RO16 – Soyal 16 Channel Digital Output Module
16 relay interface for lift access system. Each interface can be looped to support multiple of 16 floors.
AR727i – Soyal TCPIP Networking Module
-TCPIP module for AR716E.
-Convert RS485 to TCPIP
-Can assign an IP for access by PC via TCPIP network
Add on module to expand 8 more digital input port on AR716E for alarm monitoring function in software.
